3 Boot Remote Control Heavy Type Log Car

Internal Hook Movement: Hydraulic.
Hook drive System: Hydraulic.
Car going and coming: Reducer Motor with Double Rope.
Body: Steel Body.
Measurement system: Digital ( plc-touch) screen.
Lubrication System: Automatic (timed) lubrication.
Remote Control Panel: In Platform Form.
Daily Log Cutting Capacity: 70 - 80 m³.
Hydraulic Unit Motor: 11 KW 1500 Rpm.
Boot Drive System: 7.5 KW Reducer Motor.
Rotation System: 3 KW Reducer Motor.
Boot Progress Speed: 310 mm/sec.
Car Progress Speed: 115 m/min.
Log Diameter Max: 1000 mm.
Max. Opening Of Hooks: 1000 mm.
Max. Opening Of Boots: 1000 mm.
Rail Width (Center To Center): 1520 mm.
Distance Between Hooks: 125 cm x 225 cm (Optional).
Dimensions: 225 cm x 570 cm x 180 cm (WxLxH).
Weight: 6500 Kg.
