HEAT RECOVERY SYSTEMS FROM WASTE HEAT -SCOTCH TYPE
3 PASS, FIRE-SMOKE TUBE HOT WATER BOILER Tip : SSK
OIL AND NATURAL GAS-FIRED
DESIGN :
High pressure,3 pass,fire-smoke tube Scotch type overheated/hot water boilers are manufactured according to EN 12953
Lloyd rules,TRD,DIN and EN norms.
MATERIALS:
Cylinder shell,flue plates and combustion chamber are manufactured from P265 GH(boiler sheet) Smoke tubes are seamless boiler tubes(according to EN 10028-2)
HIGH EFFICIENCY:
Flue gases, formed as a result of good combustion, pass through convection surfaces and leave the boiler without causing low-temperature corrosion. maximum heat transfer and high efficiency (88-90%) is obtained.
